• Option

1. - Hybrid recorder
2. - Gas connection service
3. - MFC, Digital Vacuum Meter (Bullseye)



• Safety Device

1. - Automatic reset function incoming power cut
2. - Buzzer on when set time arrived
3. - Over temperature alarm

Lab Mobile Hood Usage Examples



Digital Vacuum Meter(Bullseye)

• Convenient to use as a portable device, and can operate continuously for 70 hours using AA batteries (4EA)
• Power connection via micro USB port is possible
• It can be freely installed on the case surface using the rear magnetic plate and can also be placed on a stand.
• Accurate vacuum readings with Agilent 536 sensor pre-calibrated to NIST standards
• Display vacuum measurement values as text or easy-to-recognize graphs (0.001 to 800 Torr)
• 12 measurement units can be displayed (Torr, mbar, bar, kPa, inches of Hg, mm Hg, millitorr, microns, inches of water, PSI, Pa)



Model	Bullseye
Range	0.001 Torr - 800 Torr
Power	AA x 4 Batteries
Sensor	Agilent 536 Sensor
Accuracy	± 0.002 Torr or 20%
	± 10%
	± 25%
Units	Torr, millitorr, microns, mbar, bar, kPa, Pa, mm, mm of Hg, inches of Hg, inches of water, PSIA
Mount	Portable Handheld
Display	LCD
Certifications	CE, RoHS2

• Standard Accessory

1. - Bullseye Gauge & Agilent536 Vacuum Sensor 1SET
2. - KF(NW)25 Clamp 1EA
3. - KF(NW)25 Centr Ring & Viton Ring 1EA
4. - USB C type charger 1EA

• Option

1. KF(NW)25 Hose Barb 10mm
2. KF(NW)16, 25, 40 Clamp
3. KF(NW)16, 25, 40 Centr Ring & Viton Ring
4. KF(NW)25 T Connector
5. KF(NW)25 L Connector
6. KF(NW)25 Ball Valve
7. KF(NW)25 Blank
8. KF(NW)40*25 Reducer
9. KF(NW)25*16 Reducer
10. KF(NW)25&1/4"PT Needle Valve
11. KF(NW)16&1/4"PT 3-Way Valve
12. Silicon Vacuum Hose 8-15mm(L)5m
13. SUS Bellows Hose 1m

Vacuum Accessories



Mass Flow Controller (Multi gas selectable)

• Accessible PID valve tuning for best speed and stability.
• Custom valve orifice sizes: yields full-range stability.
• Control mass flow, volume flow, or pressure with one device.
• No warm-up: ready to control process flows in one second.



Model	MC Series	MCS Series	MCSS Series	MCV Series
Type	General	For Toxi Gas	For Toxi Gas (including Cl2, SO2, HCl)	For Vacuum
Flow Range	0 ~ 1 slpm / 0 ~ 5 slpm
Mass Flow Accuracy at calibration conditions	±0.6% of reading or ±0.1% of full scale	±0.8% of reading or ±0.2% of full scale
Operating Temperature Range	-10 to +60°C
Temperature Accuracy	±0.75°C
Operating Pressure full scale	145 PSIG
Pressure Accuracy	Above 1 atm: ±0.5% of reading
Typical Indication Response Time	< 10 ms	< 100 ms
Typical Warm-Up Time	<1 Second
Monochrome LCD	Simultaneously displays mass Flow, pressure and temperature	Simultaneously displays mass Flow, Volumetric Flow, pressure and temperature
Mechanical Dimensions (HxWxD)	104.14x91.44x27.94mm / 4.1x3.6x1.1"			121.92x172.72x38.1mm / 4.8x6.8x1.5"
Gas Selectable	98 Gas	128 Gas (except Cl2, SO2, HCl)	131 Gas (including Cl2, SO2, HCl)	98 Gas
Communication	RS-232

Gas Select™ Preloaded Gases



Programmable Controller

• High precision (0.1%), high functionality
• Supports multi-input (T/C, RTD, DCV)
• Multi-output and simultaneous output (Max. 5 points) possible
• Easy parameter manipulation and textualization of setting values
• Supports overshoot suppression function
• RUN/STOP possible by external contact input
• Display of the driving screen in auxiliary output status
• A total of 30 segments are possible in 2 patterns.
• Supports various auxiliary outputs (IS, TS, PEND, etc.)
• Input compensation function by section (Max 4 Zone)
• Equipped with PID automatic compensation function (AT Gain)
• Supports various communication protocols (other than Modbus)
• Realizing high quality and high reliability (CE, CUL, ISO, etc.)



Display	Size(WxHxL)	96x96x68mm(3.8x3.8x2.68'') / 72x72x68mm(2.83x2.83x2.68'')
	PV/SP Display	4 Digit
Operation Mode		Program / Reset, 2 Zone PID
Control Mode		1CH Control
Max Channel		-
Patterns & Segments		2 Patterns / Max 30 segments
Input	TC	K, J, E, T, R, B, S, L, N, U, W, C, Platinel Ⅱ
	RTD	Pt100Ω, JPt100Ω
	Analog Voltage Input	-10~20mV, 0~100mV, 0.4~2.0V DC, 1~5V DC, 0~10V DC
Output	Control Output	RELAY, SSR(Voltage Pulse)
	Current Output	4 ~ 20mA DC
	Voltage Output	-
	Transmission Output	4 ~ 20mA (PV, SP, MV)
Digital Input	Contact Type	2 Points / 4 Types (RUN, HOLD, STEP, RESET)
	Contact capacity	-
Digital Output	Relay	Normal Open 30V DC A, 250V AC 1A Normal Close 30V DC3A 250V AC 3A
	Open Collector	ON voltage across contacts at less than 2V, the leakage current less than 100㎂
Sampling Time		250ms
Accuracy		±0.1% ±1% digit of Full Scale
Event	Alarm	1 Point / Max 3 Points (20 Types)
	Inner Signal	2 Points (PV, SP, TSP)
	Time Signal	1 Point
	Other	1 Point (RUN, Pattern END, UP, DOWN, SOAK)
Communication	Interface	RS485
	Protocol	PC-Link, MODBUS (ASCII, RTU), SYNC (Master, Slave)
	Speed	Max 115,200 bps
Power	Power	100 ~ 240V AC, 50 ~ 60Hz
	Power Consumption	Max 10W
Operating environment		-
Weight		-

Flue Gas Analyzer
Smart Combustion Gas Analyzer

testo 300

• Measurement of combustion gases such as O2, CO, NO, combustion efficiency, and furnace pressure is possible.
• Capable of measuring high concentration CO up to 30,000 ppm
• Intuitive measurement menu support for heating installation professionals
• Supports App to App interface that allows data transfer to other systems



Product Name	Smart flue gas analyzer Testo 300
Model	Testo 300
certification	TÜV certified (1st German Federal Immission Control Ordinance (BImSchV))
Storage temperature	-20 ~ +50°C
Operating temperature	-5 ~ +45°C
Charging temperature	0 ~ +45°C
Humidity application range	15 ~ 90% RH (non-condensing)
Power supply	Rechargeable battery, charging device using USB adapter
Battery life	10 hours
Protection class	IP 40
Memory	Up to 1,000,000 measurements can be stored
display	5 inch touch display, HD 1280x720 pixels, IPS (160 k)
weight	About 800 g
size	Length: 244 mm (probe connected) Height: 59 mm Width: 98 mm

Technical Data

Measurement items	Measurement range	Accuracy (±1 digit)	Resolution
O₂ measurement	0 ~ 21 vol.%	±0.2 vol.%	0.1 vol.%
CO measurement (without H₂ compensation)	0 ~ 4,000 ppm	±20 ppm (0 to 400 ppm) ±5% of reading (401 to 2,000 ppm) ±10% of reading (2,001 to 4,000 ppm)	1 ppm
CO measurement (H₂ compensation)	0 ~ 8,000 ppm	±10 ppm or ±10% of reading (0 to 200 ppm) ±20 ppm or ±5% of reading (201 to 2,000 ppm) ±10% of reading (2,001 to 8,000 ppm)	1 ppm
CO measurement (without H₂ compensation and dilution)	0 ~ 15,000 ppm	±200 ppm or ±20% of reading	1 ppm
CO measurement (H₂ compensation and dilution)	0 ~ 30,000 ppm	±100 ppm or ±10% of reading	1 ppm
NO measurement	0 ~ 3,000 ppm	±5 ppm (0 to 100 ppm) ±5% of reading (101 to 2,000 ppm) ±10% of reading (2,001 to 3,000 ppm)	1 ppm
Efficiency (Eta)	0 ~ 120%		0.1%
combustion gas loss	0 ~ 99.9%		0.1%
CO₂ measurement (calculated value)	Display range 0 ~ CO₂ max.	±0.2 vol.%	0.1 vol.%
Pressure measurement	-9.99 ~ +40 hPa	±0.005 hPa (0 to 0.1 hPa) ±0.02 hPa (0.1 to +3.00 hPa) ±1.5% of reading (+3.01 to +40 hPa)	0.001 hPa (0 ~ 0.1 hPa)  0.01 hPa (remaining range)
4 Pa measurement (dilution function)	-50 ~ +50 Pa	±0.3 Pa (<10 Pa) ±3% of reading (remaining range)	0.1 Pa
Pressure measurement	-100 ~ 200 hPa	±0.5 hPa (0 to +50.0 hPa) ±1% of reading (+50.1 to +100.0 hPa) ±1.5% of reading (+100.1 to +200 hPa)	0.01 hPa
Temperature (Meter)	-40 ~ +1,200°C	±0.5°C (0.0 to +100.0°C) ±0.5% of reading (remaining range)	0.1°C (-40 to +999.9°C) 1°C (remaining range)
Ambient CO measurement (meter/flue gas probe)	0 ~ 2,000 ppm	±10 ppm (0 to 100 ppm) ±10% of reading (101 to 2,000 ppm)	1 ppm
Ambient CO measurement (Atmospheric CO measurement probe connection)	0 ~ 500 ppm	±3 ppm (0 to 29 ppm) ±10% of reading (30 to 500 ppm)	1 ppm

• Standard Accessory

1. - USB power adapter

• Option

1. - Bluetooth Printer 0554 0621 (Includes 1 roll of printer paper and 4 batteries)
2. - Printer paper (6 rolls per pack)
3. - Testo 300case



Flue Gas Analyzer
Industrial Combustion Gas Analyzer

• Possible to measure exhaust gases from industrial sites such as O2, CO, NO, NO2, SO2, etc.
• Up to 5x expandable measurement range (when equipped with slot 2)
• Supports automatic sensor protection when measuring high concentration gases



Product Name	Industrial flue gas analyzer Testo 340
Model	Testo 340 Nox	Testo 340 Sox
Memory	Up to: 100 folders can be created Per folder: Up to 10 points (sites) can be set Per point (site): Up to 200 measurement records can be stored The maximum number of records is determined by the number of folders or sites.
Custom Fuel	O2, CO, NO, NO2	O2, CO, SO, SO2
pump	Pump flow rate: 0.6 l/min (adjustable) Hose length: up to 7.8 m (2 hose extensions) Max. positive pressure: +50 mbar Max. negative pressure: -200 mbar
weight	960 g
size	283 x 103 x 65 mm
Storage temperature	-20 ~ +50 °C
Operating temperature	-5 ~ +50 °C
display	Korean display 160 x 240 pixels
Power supply	Battery 3.7 V / 2.4 Ah Charging Cable 6.3 V / 2 A
Housing Material	TPE PC
Protection class	IP40

Technical Data

Measurement items	Measurement range	Accuracy (±1 digit)	Resolution	Reaction time t90
O₂ measurement	0 ~ 25 Vol. %	±0.2 Vol. %	0.01 Vol. %	within 20 seconds
CO measurement (H2 compensation)	0 ~ 10,000 ppm	±10 ppm or ±10% of reading (0 to 200 ppm) ±20 ppm or ±5% of reading (201 to 2,000 ppm) ±10% of reading (2,001 to 10,000 ppm)	1 ppm	within 40 seconds
COlow measurement (H2 compensation)	0 ~ 500 ppm	±2 ppm (0 to 39.9 ppm) ±5% of reading (remaining range)★ ★ The value applies when the ambient temperature is 20°C.   The additional temperature coefficient is 0.25%/K of the reading.	0.1 ppm	within 40 seconds
NO measurement	0 ~ 4,000 ppm	±5 ppm (0 to 99 ppm) ±5% of reading (100 to 1,999 ppm) ±10% of reading (2,000 to 4,000 ppm)	1 ppm	Within 30 seconds
NOlow measurement	0 ~ 300 ppm	±2 ppm (0 to 39.9 ppm) ±5% of reading (remaining range)	0.1 ppm	Within 30 seconds
NO2 measurement*	0 ~ 500 ppm	±10 ppm (0 to 199 ppm) ±5% of reading (remaining range)	0.1 ppm	within 40 seconds
SO2 measurement*	0 ~ 5,000 ppm	±10 ppm (0 to 99 ppm) ±10% of reading (remaining range)	1 ppm	within 40 seconds
Temperature measurement	-40 ~ +1,200 °C	±0.5 °C (0 to +99 °C) ±0.5% of reading (remaining range)	0.1 °C
Using a thermocouple type K probe	-40 ~ +40 hPa	±0.03 hPa (-2.99 to +2.99 hPa) ±1.5% of reading (remaining range)	0.01 hPa
Pressure measurement	-200 ~ 200 hPa	±0.5 hPa (-49.9 to 49.9 hPa) ±1.5% of reading (remaining range)	0.1 hPa
4 Pa measurement (dilution function)	600 ~ +1,150 hPa	±10 hPa	1 hPa
Pressure measurement	0 ~ 120%		0.1 %
Temperature (Meter)	0 ~ 99.9%		0.1 %
Ambient CO measurement (meter/flue gas probe)	0 ~ 99.9 °C		0.1°C
Ambient CO measurement (Atmospheric CO measurement probe connection)	0 ~ CO2 max.	±0.2 Vol. %	0.1 Vol. %	within 40 seconds

* Do not exceed the maximum measurement time of 2 hours.

• Standard Accessory

1. - Power adaptor
2. - Probe adaptor

• Option

1. - Printer 0554 0549 (Includes 1 roll of printer paper and 4 batteries)
2. - Printer paper (6 rolls per pack)
3. - Testo 340case



Areas of application

• Destructive testing laboratories who carry heat treatment of ceramic, alloy, titanium and etc for aerospace and metallic production industries.
• Research, development and production of sintering metal powders such as nickel alloy.
• Building companies who transform metallic powders such as nickel alloy into sintered materials by sintering.
• Material technology providers who develop polymer composites and graphene materials.
• Aerospace companies that perform cyclic oxidation tests between high temperature to room temperature in atmosphere-controlled environment.
• Medical and healthcare companies who need analysis of ashes and contents through combustion of materials.
• Material innovation companies who do sintering in vacuum or in inert gases.
• Research, development and production of subsea and surface injection system companies who need vacuum furnace for softening cycles, annealing and age hardening of Inconel 718 tubes.
• Analytical research labs who perform various material testing with thermal treatment.
• Medical implants manufacturers who anneal alloy powders.
• Material scientists in universities who do sintering materials such as polymer-derived ceramic parts.
• Applied science engineers who process solid oxide fuel cells (SOFC).
• Environmental and chemical researchers who need combustion of materials.
• Regulatory compliance service providers in the areas of hazardous waste thermal treatment, air permitting, air pollution control, contaminated soil remediation, and hazardous waste management.
• Metallic parts manufacturers who need vacuum brazing and heat treating for steel.
• Water treatment companies who test glass content in FRP (fiber reinforced polymer) products according to ASTM D2584.
• Semiconductor manufacturers who anneal Gallium nitride (GaN) semiconductor wafers.
• Engineering companies who do curing and sintering solutions in porous ceramic tubes.
• Civil engineers who need soil combustion.
• University labs who anneal Si wafer in vacuum condition.
• Chemistry research departments who do the thermal treatments (stabilization in air and carbonization in argon) of carbon nanofiber precursors.
• Marine equipment manufacturers who analyze ash content in marine HFO (Heavy Fuel Oil).
• Graphene research, development and production of graphene-based materials using chemical vapor deposition (CVD).
• Graphene solution companies who produce graphene-based materials by CVD (Chemical Vapor Deposition) method.
• Development of next-generation solid-state batteries using polymer electrolyte, oxide electrolyte, sulfide electrolyte, phosphate electrolyte, etc.
