SH Fume Hood – 1500UP

Fume Hood(5')

1500x800x2350(mm)



  • 1500mm length and 800mm depth
  • Convenient operations with valve and electric side arrangement
  • Dome-type duct design to eliminate swirl and residual conditions
  • Reduce Co2 emissions by 38%, reduce power consumption by 62% (performance certified)
  • Phenolic laminate inside, excellent chemical resistance
  • Specification

  • Documents

  • Inquiry

  • Fume hood is a type of local ventilation device that is designed to limit exposure to hazardous or toxic fumes, vapors or dusts.

    * Convenient operations with valve and electric side arrangement
    * Dome-type duct design to eliminate swirl and residual conditions
    * Reduce Co2 emissions by 38%, reduce power consumption by 62% (performance certified)
    * Phenolic laminate inside, excellent chemical resistance
    * Easy fit removable inspection hole
    * Operation indicator lamp (green) and sound alarm



  • Model SH-HD-1500UP
    Type Fume Hood Type
    Dimension External
    (WxDxH)
    1500x800x2350mm
    59.06×31.50×92.52″
    Dimension Internal
    (WxDxH)
    1324x676x1160mm
    52.13×26.64×45.67″
    Structure AL. Profile
    Exterior Phenolic Laminate
    Interior / Baffle Phenolic Laminate
    Work Top Phenolic Laminate, Epoxy, P.P / P.V.C, Stainless steel, Stoneware
    Sash Tempered Safety Glass 5.0T / Transparent clear
    Utility Air / N2 / Water
    Cock & Valve P.P / Brass
    Lamp LED
    Lamp case Explosion proof / Vapor proof – Optional
    Electrical supply External socket, 110V/220V. 60Hz
    Controller LCD Touch controller – Optional
    Cat. No.120V HD1500UP120
    Cat. No.230V HD1500UP230
