IS-RDS4

Shaking Incubator

IS-RDS4

Loadable programmable shaking incubator
Stackable Incubator Shakers
(TEMP / RPM / Humi Alarm)

  • 250Liter, 3-level loading, 26mm wide rotation
  • ±0.3°C temperature uniformity
  • Triple Eccentric Drive system for stable and low-noise operation (<53dB) even at maximum speed (300R.PM)
  • Excellent performance in suspension cell culture
  • 10" Large LCD color display control panel
  • Temperature / Shaking speed (RPM) / CO2 program control 12 Program
  • Humidity Alarm Function
  • USB datalogger function
  • Sliding rack style for ease of use
  • Automatic load balancing system

  • Specification

  • Inquiry

  • Selection Guide
    Stackable Shaking Incubator

    Display IS-AX
    IS-RDS4 IS-RDS4T IS-RDS4C5 IS-RDS4C5T IS-RDS4C5H IS-RDS6 IS-RDS6T IS-RDS6C5 IS-RDS6C5T IS-RDS6C5H
    Temp Program Control O O O O O O O O O O O
    RPM Program Control O O O O O O O O O O O
    CO2 Program Control X X X O O O X X O O O
    Humi Program Control X X X X X O X X X X O
    Humi Alarm & Display O O O  O   O  O O O
    Oribital Dia 26mm 50mm 26mm 50mm
    Door Type Leftward Downward Upward Downward Upward Downward Upward Downward Upward Downward
    Room Capacity 190L 250L 401L
    Flask Load Capa
    (1,000mL, Sticky mat)
    12 EA 15 EA 28 EA
    Flask Load Capa
    (250mL, Sticky mat)
    30 EA 40 EA 77 EA




    Wide-range shaking control with 26mm Orbit Diameter for loading various types of samples and large-capacity cultivation of up to 20kg




    12 Program Temperature, speed setting possible Data download possible using USB
    Fix/Program mode operation possible (Save Excel File)




    Providing various driving environments through 10'' touch panel.
    Datalogger function allows you to check driving status and alarm status through the touch panel.

    Shaking incubator detailed features

    Curve Display of Temperature, Speed, CO2 Humidity Recovery Time after Open Door 30sec

    Shaking incubator detailed features

    Product Name Stackable Incubator Shaker(250L Touch Screen)
    Model IS-RDS4
    Platform Dimensions 770x470mm / 30.31x18.50''
    Max. Capacity Clamp Capacity: 50mlx104 / 100mlx45 / 150mlx45 / 200mlx45 / 250mlx40 / 500mlx25 / 1000mlx15 / 2000mlx12 / 5000ml(Thomson)x6
    Sticky Mat: 50mlx112 / 100mlx72 / 150mlx60 / 200mlx45 / 250mlx40 / 500mlx28 / 1000mlx15 / 2000mlx12 / 5000ml(Thomson)x6
    Capacity 250L
    Max. Load 20kg
    Temp Control  12program Range Room Temp. - 18℃~60℃ (Lowest Temp. is 4℃), Accuracy ±0.1℃, Uniformity ±0.3℃ (@37℃)
    Speed ​​Control  12program Range 0 (Stop), 30~300rpm, Accuracy ±1rpm
    Orbit Diameter φ26mm
    CO2 Sensor NA
    CO2 Control Range NA
    CO2 Control Accuracy NA
    Max. Humidity Alarm 95% (only alarm function)
    Illumination Both Side Lamps
    Disinfection Both Side UV Lamps
    Door Open Direction Downward
    Date Curve Display Temp. Curve, Speed ​​Curve
    Display 10" Color Capacitanec Touch Screen
    Display the Date In 7 days
    Date Store Types More than 912 days
    Date Store Time 1min
    Date Store Types Time, Temp, Speed, Machine Status
    Third Platform High 1345mm
    Noise Level ≤55dB(In Refrigerating)
    Water Sparge Resistant Yes
    Auto-run after Power Recovery Yes
    Heat Power ≤850W
    Cool Power 70~230W
    Power ≤950W
    Power Supply AC 220V±22V,50Hz/60Hz
    Dimension External
    (W×D×H)
    1240x785x615mm / 48.82x30.91x24.21''
    Operation Chamber Height 305mm / 12.01''
    Net Weight 255kg

    Options

    Remote Monitor & Control System & APP>

    Remote Monitor & Control System & RS485

    Mobile wireless monitoring software for internet or local area network, which can monitor and control the incubating shaker. All parameters of the device can be monitored and controlled by mobile phone, and more than one system can be monitored and controlled by multiple mobile phones. You can check the historical data in the mobile phone and optimize the parameters later.

    • Monitor multiple shakers simultaneously with one mobile device
    • Monitor and control temperature, speed, humidity, CO2, lighting, and other parameters via LAN and Internet
    • The device can be programmed and run multiple section programs (up to 12)
    • Receive alarm information via mobile device
    • View historical data including temperature, speed, humidity, CO2, light, and other historical parameters via your mobile device

    Accessories




    Model Part Number Specifications Note
    Flask Clamp IS-A1 50ml Stainless steel material, compatible with all shakers
    IS-A2 100ml
    IS-A3 150ml
    IS-A4 200ml
    IS-A5 250ml
    IS-A6 500ml
    IS-A7 1000ml
    IS-A8 2000ml
    IS-A9 3000ml
    IS-A10 5000ml
    IS-A50 25ml




    Model Part Number Specifications Note
    Test Tube Rack IS-A11 40xØ14mm (0.55'') Stainless steel / High quality ABS material, compatible with all shakers
    Dimension External (W×D×H):
    262x112x140mm
    (10.31x4.41x5.51'')
    IS-A12 40xØ16mm (0.63'')
    IS-A23 40xØ18mm (0.71'')
    IS-A24 27xØ22mm (0.87'')
    IS-A42 21xØ30mm (1.18'')




    Model Part Number Specifications Note
    Adjustable Test Tube Rack IS-A20 40xØ14mm (0.55'') Stainless steel / High quality ABS material, compatible with all shakers
    Dimension External(W×D×H):
    267x125x172mm
    (10.51x4.92x6.77'')
    IS-A21 40xØ16mm (0.63'')
    IS-A30 40xØ18mm (0.71'')
    IS-A31 27xØ22mm (0.87'')
    IS-A32 27xØ30mm (1.81'')
    IS-A37 24xØ30mm (1.81'') Stainless steel, material, for 300mm long tube
    Dimension External(W×D×H):
    267x125x172mm
    (10.51x4.92x6.77'')




    Model Part Number Specifications Note
    Multifunction Spring Platform IS-A19 WxDxH: 165x165x80mm (13.78x9.45x3.15'') For all shakers. Stainless steel material, can be mounted on the shaker platform
    IS-A27 WxDxH: 350x240x80mm (13.78x9.45x3.15'')
    IS-A22 WxDxH: 450x400x80mm (17.72x15.75x3.15'') For all of incubator shakers except IS-RSDA.
    IS-A14 WxDxH: 428x295x80mm (16.85x11.61x3.15'')
    IS-A39 WxDxH: 720x440x80mm (28.35x17.32x3.15'') For IS-RDS3, RDS4
    IS-A48 WxDxH: 840x440x80mm(33.07x17.32x3.15'') For chest-type incubator shakers.




    Model Part Number Specifications Note
    Fixture for Separating Funnel IS-A25 WxDxH: 355x402x153mm
    (13.98x15.83x6.02'')
    For separating funnel for 5L
    IS-A35 N/A For separating funnels of 0.5L or more




    Model Part Number Specifications Note
    Infusion Bottle Clamp IS-A33 500ml Stainless steel material, compatible with all shakers
    IS-A34 1000ml




    Model Part Number Specifications Note
    Sticky Pad IS-A47 WxD:140x140mm
    (5.51x5.51'')
    Compatible with all shakers, ready to use within minutes after washing with water




    Model Part Number Specifications Note
    Rack for Stackable
    Incubator Shakers
    IS-A29 WxDxH: 948x630x225mm
    (37.32x24.80x8.86'')
    For multi-stage shaker
    For IS-RDS3, IS-RDS3C, IS-RDS4
    IS-A62 WxDxH: 1440x775x330mm
    (56.73x30.51x12.99'')
    For multi-stage shaker
    For IS-RDS6, IS-RDSC6C Series
    IS-A91 WxDxH: 1241x651x340mm
    (48.86x25.63x13.38")
    For multi-stage shaker
    For IS-RDS4, IS-RDSC4C Series
    IS-A93 WxDxH: 971x625x340mm
    (38.23x24.60x13.38")

    For IS-AX for multi-stage shaker




    Model Part Number Specifications Note
    Flask Holder IS-A26 5000ml For 5L flask
    (For IS-RDS, IS-RDS3C, IS-RDH2, IS-RSH2)




    Model Part Number Specifications Note
    96-Well Microplate Holder IS-A13 WxD: 136x95mm (5.35x3.74'') Compatible with all shakers




    Model Part Number Specifications Note
    Universal Spring Platform WBA30 WxDxH: 370x240x180mm
    (14.57x9.45x7.09'')
    SY-2330-03A, Maximum Capacity:1




    Model Part Number Specifications Note
    Deep Well Plate Clamp IS-A61 WxDxH: 780x450x84mm
    (30.71x17.72x3.31'')
  • Product Name Stackable Incubator Shaker(250L Touch Screen)
    Model IS-RDS4
    Platform Dimensions 770x470mm / 30.31x18.50''
    Max. Capacity Clamp Capacity: 50mlx104 / 100mlx45 / 150mlx45 / 200mlx45 / 250mlx40 / 500mlx25 / 1000mlx15 / 2000mlx12 / 5000ml(Thomson)x6
    Sticky Mat: 50mlx112 / 100mlx72 / 150mlx60 / 200mlx45 / 250mlx40 / 500mlx28 / 1000mlx15 / 2000mlx12 / 5000ml(Thomson)x6
    Capacity 250L
    Max. Load 20kg
    Temp Control  12program Range Room Temp. - 18℃~60℃ (Lowest Temp. is 4℃), Accuracy ±0.1℃, Uniformity ±0.3℃ (@37℃)
    Speed ​​Control  12program Range 0 (Stop), 30~300rpm, Accuracy ±1rpm
    Orbit Diameter φ26mm
    CO2 Sensor NA
    CO2 Control Range NA
    CO2 Control Accuracy NA
    Max. Humidity Alarm 95% (only alarm function)
    Illumination Both Side Lamps
    Disinfection Both Side UV Lamps
    Door Open Direction Downward
    Date Curve Display Temp. Curve, Speed ​​Curve
    Display 10" Color Capacitanec Touch Screen
    Display the Date In 7 days
    Date Store Types More than 912 days
    Date Store Time 1min
    Date Store Types Time, Temp, Speed, Machine Status
    Third Platform High 1345mm
    Noise Level ≤55dB(In Refrigerating)
    Water Sparge Resistant Yes
    Auto-run after Power Recovery Yes
    Heat Power ≤850W
    Cool Power 70~230W
    Power ≤950W
    Power Supply AC 220V±22V,50Hz/60Hz
    Dimension External
    (W×D×H)
    1240x785x615mm / 48.82x30.91x24.21''
    Operation Chamber Height 305mm / 12.01''
    Net Weight 255kg
